T12 는 복잡하고 열악한 환경에서 작동하는 농업, 엔지니어링 및 물류 차량을 위해 설계된 고성능 및 견고한 차량 탑재형 컴퓨터입니다.
이 제품은 자동차 등급의 64비트 프로세서를 채택하고 안드로이드 13 또는 리눅스 시스템을 지원하며, 고휘도 디스플레이와 다양한 통신 인터페이스를 제공합니다.
옵션 사양인 센티미터급 RTK GNSS 위치 측정 모듈을 통해 T12는 자동 또는 반자동 주행, 정밀 농업 및 차량 관리 애플리케이션의 요구 사항을 충족할 수 있습니다.
| Type | IPS screen | Port | Power button x1 |
| Size | 12.1" | USBC port x1 (for software debugging) | |
| Resolution | 1280x800 | USB Host A port x1 | |
| Brightness | >=750 CD/M2 | TF Card x1 | |
| View Angle | >=170 degrees | Nano SIM Card x1 | |
| Touchscreen | Full lamination, multi-touch | TNC antenna port x2 (for external high-precision GNSS positioning antenna) | |
| System | SMA antenna port x1 (for external LTE communication antenna) | ||
| Processor | 64-bit, 8-core Cortex A55@1 .8GHz | 4Pin aviation x4 (for 1080P Cameras) | |
| Memory | 4GB | 26PIN connector x1 (function extension interface) | |
| Storage | 64GB (optional 256GB) | Function Extension | Default function: 2*CAN+2*RS232+1*RS485+1*100M Ethernet+1*GPIO |
| OS | Android 13.0 (optional LINUX kernel5.15+QT5.15) | Combo 1 function: 2*CAN+1*RS485+1*100M Ethernet | |
| RF Communication | Combo 2 function: 1*CAN+3*RS232 | ||
| WIFI | 2.4G WiFi, IEEE802 .11 b/g/n/ac | Combo 3 function: according to request | |
| BT | BT4 .0 BLE | Environment | |
| GNSS | GPS+BD module（optional） | Vibration | MIL-STD-810 |
| High Precision Positioning | Support RTK module UM982 or UMD982 (optional) | Impact | ISO16750 |
| 4G LTE | Module Model:：Quectel EC200G/EC800G CAT1 (For China） Optional 4G Module：Quectel EC25-G (For Global Market） Carrier Certifications: Deutsche Telekom (Europe), Verizon / AT&T / Sprint / U.S. Cellular | Working Temperature | -20°C～+70°C |
| Physical | Humidity | 95%, non-condensing | |
| Power | 9 ~ 36V DC (ISO 7637-II) | IP Rating | IP66 |
| Dimensions | 310x212x38 mm |
Provides secure and stable mounting for vehicle installations. Compatible with VESA mounting solutions for flexible deployment.
Delivers high-precision RTK positioning for demanding applications.
Compact USB camera for driver monitoring and video capture.
Heavy-duty mounting bracket for larger vehicle terminals.
Automotive-grade mainboard delivering stable performance for rugged vehicle computing applications.
Waterproof rear-view camera for reliable outdoor operation.
Provides power, I/O, CAN Bus, serial ports, and other interface connections for industrial applications.
High-precision GNSS module supporting accurate positioning for navigation and RTK-enabled applications.
Enhances 4G signal strength for stable wireless connectivity.
Adds reliable 4G LTE communication for real-time data transfer.
Supports accurate GPS and BeiDou positioning for navigation.
Suitable for commercial vehicles and off-highway equipment, including agricultural tractors, excavators, cargo and transport trucks, engineering cranes, autonomous mining trucks, heavy-duty trucks, buses, and ride-hailing vehicles.
